60V 30Ah Electric Vehicle Battery
60V 30Ah Electric Vehicle Battery
- Nominal Energy: 1920Wh
- Nominal Voltage: 64V
- Energy Capacity: 30Ah
- Cycle Life: ≥3000 cycles
- Range: 70km(1000W)
- Storage Temperature: -30~60℃
- Size(L*W*H) ：360*213*185mm
- Weight ：≈17kg
Description
Description
Electric vehicle batteries are specifically designed to provide powerful, efficient, and long-lasting energy storage for all types of electric cars.
With ongoing advancements, these batteries are becoming more cost-effective, safer, and environmentally friendly technology.
| Model NO | 48V20Ah | 60V20Ah | 48V30Ah | 60V30Ah | 72V30Ah |
| Material | LiFePO4 | ||||
| Nominal Voltage | 51.2V | 64V | 51.2V | 64V | 73.6V |
| Nominal Capacity | 20Ah | 20Ah | 30Ah | 30Ah | 30Ah |
| Standard Energy | 1024WH | 1280WH | 1536WH | 1920WH | 2208WH |
| Net Weight | 8kg | 10kg | 13kg | 17kg | 21kg |
| Dimension | 150*170*245mm | 150*170*285mm | 300*160*160mm | 360*213*185mm | 165*215*300mm |
| Maximum Charging Current | 10A | 10A | 15A | 15A | 15A |
| Charging Cut-off Voltage | 58.4V | 73V | 58.4V | 73V | 84V |
| Continuous Discharging Current | 20A | 20A | 50A | 50A | 50A |
| Discharge Cut-off Voltage | 40V | 50V | 40V | 50V | 57.6V |
| Instantaneous Maximum Current | 60A | 60A | 120A | 120A | 120A |
| Range | 71km(350W) | 65km(500W) | 78km(500W) | 70km(1000W) | 80(1000W) |
| Cycle Life | 3000cycles, capacity≥80% | ||||
| Storage Temperature | -30~60℃ | ||||
| Warranty Period | 3 years | ||||
| Operating Temperature | Discharging:-20℃~55℃ Charging:0℃~45℃ | ||||
